Stainless hlau Structured Packing

Stainless Hlau Hlau Structured Packing Kem Ntim Rau Distillation Kem yog ua los ntawm perforated phaj nrog channel corrugation rau saum npoo, thiab tseem muaj cov txheej txheem ntawm cov hlau xaim gauze packing. Nws ntxiv dag zog rau cov kua dej tsis sib xws thiab muaj peev xwm ntub dej, uas ua rau muaj kev hloov pauv loj.

Xa kev nug

Khoom Taw qhia

Stainless hlau Structured Packing Taw qhia:

Stainless Steel Structured Packing kem packing feem ntau muaj cov hlau thiab corrugated hlau los xij, uas yog zoo zoo nyob rau hauv lub pej thuam nyob rau hauv ib tug niaj hnub geometry. Nws yog dav siv nyob rau hauv reactors nyob rau hauv zoo tshuaj, petrochemical, chiv thiab lwm yam lag luam raws li ib tug loj hloov nruab nrab, thiab yog feem ntau siv nyob rau hauv lub tshuab nqus tsev distillation, atmospheric distillation thiab nqus cov txheej txheem uas nyuaj rau cais thiab muaj cua sov.

Stainless Steel Structured Packing yog ua los ntawm carbon steel, SS304, 304L, 410, 316, 316L thiab lwm yam ntaub ntawv.

Qauv:

125Y, 250Y, 350Y, 500Y, 125X, 250X, 350X, 500X.

Daim ntawv thov:

Stainless Hlau Hlau Structured Packing Column Packing Rau Distillation Kem nrog rau ntau yam kev siv.

System: Ethyl benzene / styrene, Fatty acid, cyclohex anone / cyclohexanol, caprolaction, thiab lwm yam, Absorption desorption.

Technical Parameter:

Hom	Qhov chaw tshwj xeeb yog m2 / m3	Tsis muaj Volume feem pua	Heaping Nyhav Kg / m3	Wave Qhov siab mm	Theoretical phaj tus lej m-1	Δ P Pa/m	Max F-factor m/s(kg/m3) 0.5
125Y	125	98	85-100	25.4	1.0-2.0	150	3.0
250Y	250	97	170-200	12.5	2.0-3.0	200	2.6
350Y	350	94	240-280	9	2.0-2.5	300	2.0
500Y	500	92	360-400	6.3	4.0-5.0	180	1.8
